CC0805 MLCC Ceramic Capacitor - SMD Capacitor
The CC0805 is a high-performance MLCC (Multi-Layer Ceramic Capacitor) designed for surface mount applications, providing excellent stability and reliability for a wide range of electronic circuits. With its compact 0805 package size, this SMD capacitor is ideal for use in high-density PCB layouts.
Overview
Overview
The CC0805 is a multi-layer ceramic capacitor (MLCC) that combines high capacitance values with low equivalent series resistance (ESR), making it suitable for a variety of applications in modern electronics. This surface mount device (SMD) is constructed using advanced ceramic dielectric materials, delivering superior performance in both AC and DC applications. Its compact design fits perfectly in space-constrained environments, while its robust construction ensures reliable operation under various environmental conditions.
Key Specifications
- Capacitance: Up to 10 µF
- Voltage Rating: 6.3V, 10V, 16V, 25V, and 50V options available
- Package Size: 0805 (2.0 x 1.25 mm)
- ESR: Low ESR for high-frequency applications
- Temperature Coefficient: X7R, X5R, or C0G for different stability requirements
- Operating Temperature Range: -55°C to +125°C
- RoHS Compliant
Applications
The CC0805 MLCC ceramic capacitor is versatile and can be used in various applications, including but not limited to:
- Power supply decoupling and bypassing
- RF circuits and high-frequency applications
- Signal coupling and filtering
- Timing circuits in oscillators
- Energy storage in pulse applications
- Consumer electronics, automotive systems, and telecommunications
Its reliability and performance make it a preferred choice for engineers looking to enhance circuit efficiency while minimizing size on printed circuit boards.
