RC0402JR-070RL Chip Resistor - 0402 SMD Thick Film Resistor
The RC0402JR-070RL is a high-precision chip resistor designed for surface mount applications. With a resistance value of 7 ohms and a compact 0402 package size, it is ideal for use in a variety of electronic devices and circuits.
Overview
Overview
The RC0402JR-070RL is a robust SMD resistor that combines high reliability with excellent performance characteristics. This thick film resistor is specifically designed for surface mount technology, making it perfect for modern electronic applications where space and efficiency are critical. The 0402 package size allows for a compact footprint, enabling designers to save space on printed circuit boards (PCBs) while maintaining optimal performance. With a power rating of 1/16W and a tolerance of ±5%, the RC0402JR-070RL meets the demanding requirements of various applications, including consumer electronics, telecommunications, and automotive systems.
Key Specifications
- Resistance: 7 Ohms
- Package Size: 0402 (1005 metric)
- Power Rating: 1/16W (0.0625W)
- Tolerance: ±5%
- Temperature Coefficient: 100 ppm/°C
- Material: Thick film
- Operating Temperature Range: -55°C to +155°C
Applications
The RC0402JR-070RL chip resistor is ideal for a wide range of applications due to its high reliability and excellent thermal stability. It is commonly used in applications such as:
- Consumer Electronics: TVs, smartphones, and tablets
- Telecommunications: Networking equipment and communication devices
- Automotive: Control systems and sensor applications
- Industrial Equipment: Automation and control circuits
- Medical Devices: Diagnostic and monitoring equipment
Its versatility and compact size make it suitable for both high-density and high-performance PCB layouts, ensuring that it performs consistently in various environments and conditions. The RC0402JR-070RL is a reliable choice for engineers and designers seeking quality SMD resistors for their electronic projects.
